BOE Original 15 Inch 1024x768 IPS TFT LCD Display 20Pins LVDS Interface for Industrial Use Model DV150X0M-N10

Large Image : BOE Original 15 Inch 1024x768 IPS TFT LCD Display 20Pins LVDS Interface for Industrial Use Model DV150X0M-N10

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	AISON
Certification:	ISO9001 / ISO14000/ROHS
Model Number:	DV150X0M-N10

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Blister Package/Carton
Delivery Time:	7 working days
Payment Terms:	T/T, Western Union, MoneyGram,Paypal
Supply Ability:	300k/month

Contact Now

BOE Original 15 Inch 1024x768 IPS TFT LCD Display 20Pins LVDS Interface for Industrial Use Model DV150X0M-N10

Description

LCM:	15 Inch BOE DV150X0M-N10 LCD Display	Resolution:	1024X768
LCM Outline:	326.5(W)×253.5(H)×10(D) Mm	Active Area:	304.128(W)×228.096(H) Mm
Signal Interface:	LVDS 20 Pin	Brightness:	350cd/m2
Display Mode:	TFT,Normally Black	Viewing Direction:	ALL/IPS
Operating Temp:	-20 ~ 70 °C	Storage Temp:	-20 ~ 70 °C
Application:	Industrial Display
Highlight:	15 inch industrial IPS LCD display , 1024x768 TFT LCD with LVDS , BOE original 20Pins LCD screen

BOE Original 15 Inch 1024x768 IPS TFT LCD Display 20Pins LVDS Interface for Industrial Use Model DV150X0M-N10

General Description

The DV150X0M-N10 is a 15.0 inch diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -20 ~ 70°C , and the maximal vibration level of 1.2G (11.76 m/s²). It's general features are summarized in the following: Landscape / Portrait, WLED Backlight, Life ≥ 50K hours, With LED Driver, Matte . Based on its features, we recommend that this model be applied to Industrial, Digital Signage etc.

General Data

Part Number	DV150X0M-N10 (BOE Panel)
Size	15.0 inch
Resolution	1024x768
Display Mode	IPS(Normally Black)
Viewing Angle	89/89/89/89 (Typ.)
Contrast Ratio	1000:1 (Typ.)
Response Time	30(Typ.)(Tr+Tf) ms
Dot Pitch	0.099(H) x0.297 (V) mm
Active Area	304.128(H)x228.096(V) mm
Outline Dimension	326.5 (H) x 253.5(V) × 9.7(D) mm
LCM Luminance	350cd/m2 (Typ.)
Backlight Type	48 White LEDs[12S4P],12V/600mA
Lifetime	50000Hours (Min.)
Interface	LVDS (1 ch, 8-bit) , 20pins Connector
Operating Temperature	-20°C~+70°C
Storage Temperature	-20°C~+70°C
Touch Panel	Optional Touch Panel / Customization
Industry Application	Industrial / Digital signage

Product Details

BOE Original 15 Inch 1024x768 IPS TFT LCD Display 20Pins LVDS Interface for Industrial Use Model DV150X0M-N10 0

TFT Applications:

The 15 inch BOE IPS TFT LCD displays are suitable for Industrial, Display etc.

BOE Original 15 Inch 1024x768 IPS TFT LCD Display 20Pins LVDS Interface for Industrial Use Model DV150X0M-N10 4
