5.5 inch 1080x1920 TFT LCD Module Display with MIPI interface

Large Image : 5.5 inch 1080x1920 TFT LCD Module Display with MIPI interface

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	AISON
Certification:	ISO9001 / ISO14000/ROHS
Model Number:	ZHD55017C31

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10~20usd/pc
Packaging Details:	Blister Package/Carton
Delivery Time:	7 working days
Payment Terms:	T/T, Western Union, MoneyGram,Paypal
Supply Ability:	200k/month

Contact Now

5.5 inch 1080x1920 TFT LCD Module Display with MIPI interface

Description

LCM Name:	5.5 Inch 1080X1920 LCD Module	Number Of Dots:	1080x1920
LCM Outline Size:	70.84 (H) X128.78 (V)mmx1.45mm	Active Area:	68.04 (H) X 120.96 (V)mm
Interface:	MIPI	Brightness:	350cd/m2
Display Mode:	TFT, Normally Black, Transmissive	Viewing Direction:	ALL/IPS
Operating Temperatures:	-20 To 70 ℃	Storage Temperatures:	-30 To 80 ℃
Driver IC:	JD9522Z
Highlight:	5.5 inch TFT LCD display , MIPI interface LCD module , 1080x1920 resolution TFT display

5.5 inch 1080x1920 TFT LCD Module Display with MIPI interface

Display General Description

1) Size: 5.5 Inch
2) Resolution: 1080×1920
3) Display Mode: TFT
4) Interface Mode: MIPI 31
5) Brightness: 350 cd/㎡
6) View Angle: All O’clock
7) Driver IC: JD9522Z
8) Operation Temperature: -20~70℃
9) Storage Temperature: -30~80℃

This 5.5-inch IPS TFT display has a resolution up to 1080x1920, is equipped with a MIPI interface, and has a brightness 350cd/m². The effective display area is 68.04 (H) x 120.96 (W) mm, and the overall size is 70.84 (H) x128.78 (V)mmx2.7mm. It is equipped with a capacitive touch screen (CTP), the operating temperature range is -20°C to +70°C, and the storage temperature range is -30°C to +80°C. It is suitable for special applications in industrial scenarios and supports glove touch and harsh environments.

General Data

Item	Specifications
Type	IPS
Module Size	5.5 inch TFT LCD
Active area	68.04 (H) x 120.96 (V)x1.45mm
Dimensional outline	70.84 (H) x128.78 (V)mm
Display mode	Trasflective/Transmissive
Touch panel	Capacitive Touch screen optional
Resolution	1080(H)X1920(V)
Interface	MIPI
LCD Driver IC	JD9522Z
Brightness	330cd/m2
Viewing Angle	ALL O'CLOCK
Backlight	White LED
Operating Temperature	-20°C ~ 70°C
Storage temperatures	-30°C ~ 80°C

Drawing

5.5 inch 1080x1920 TFT LCD Module Display with MIPI interface 0

Product Details

5.5 inch 1080x1920 TFT LCD Module Display with MIPI interface 2

TFT Applications

The 5.5 inch 1080x1920 FHD TFT Displays are widely used for Industrial, Smart home,Medical, Automotive ,Intelligent and other applications.

5.5 inch 1080x1920 TFT LCD Module Display with MIPI interface 5
