6.5 Inch AUO 640x480 TFT LCD Display with LVDS Interface 800 nits

Large Image : 6.5 Inch AUO 640x480 TFT LCD Display with LVDS Interface 800 nits

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	AISON
Certification:	ISO9001 / ISO14000/ROHS
Model Number:	G065VN01 V221

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	80~100usd/pc
Packaging Details:	Blister Package/Carton
Delivery Time:	7 working days
Payment Terms:	T/T, Western Union, MoneyGram,Paypal
Supply Ability:	300k/month

Contact Now

6.5 Inch AUO 640x480 TFT LCD Display with LVDS Interface 800 nits

Description

Name:	6.5 Inch AUO G065VN01 V221	Resolution:	640X480
Outline Dimension:	243(W)×184(H)×7(D) Mm	Active Area:	132.48(W)×99.36(H) Mm
Interface:	LVDS 20pin	View Direction:	ALL
Luminance:	800cd/m2	Display Mode:	TFT,Normally Black
Operating Temperatures:	-30 ~ 80 °C	Storage Temperatures:	-30 ~ 80 °C
Power Supply:	3.3V	Contrast Ratio:	1000:1
Highlight:	6.5 Inch TFT LCD Display , 640x480 TFT LCD Display , 800 nits TFT LCD Display

6.5 Inch AUO 640x480 TFT LCD Display with LVDS Interface 800 nits

General Description

The G065VN01 V221 is a 6.5 inch diagonal a-Si TFT-LCD display panel product with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized in the following: Wide Temperature, Hight Brightness, WLED Backlight, Life ≥ 70K hours, With LED Driver, U/D,L/R Reverse, 6/8 bit, Matte . Based on its features, it is recommend that this lcd model be applied to Industrial, Outdoor High Brightness etc.

General Data

Model Name	6.5 Inch AUO 640x480 TFT LCD Display
Resolution	640x480
Model Size (WHT)	243(W)×184(H)×7(D) mm
Display Area (W*H)	132.48(W)×99.36(H) mm
Interface	LVDS
Display Mode	Normally Black,Transmissive
Viewing	ALL
Brightness	800 cd/m2
Pin number	20 pin
Contrast Ratio	1000:1
Operating temperatures	-30 ~ 80 °C
Storage temperatures	-30 ~ 80 °C

Drawing

6.5 Inch AUO 640x480 TFT LCD Display with LVDS Interface 800 nits 0

Product Details

6.5 Inch AUO 640x480 TFT LCD Display with LVDS Interface 800 nits 1

TFT Applications:

This AUO 6.5 inch 640X480 TFT Displays it is recommend that this model be applied to Industrial etc.

6.5 Inch AUO 640x480 TFT LCD Display with LVDS Interface 800 nits 2
