3.5 inch 320x240 IPS TFT LCD Display Module 3.5-inch TFT LCD Screen

Large Image : 3.5 inch 320x240 IPS TFT LCD Display Module 3.5-inch TFT LCD Screen

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	AISON
Certification:	ISO9001 / ISO14000/ROHS
Model Number:	Z035Q20

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Carton/Blister
Delivery Time:	7 working days
Payment Terms:	T/T, Western Union, MoneyGram,Paypal
Supply Ability:	200k/month

Contact Now

3.5 inch 320x240 IPS TFT LCD Display Module 3.5-inch TFT LCD Screen

Description

Name:	3.5 Inch IPS TFT LCD Display	Resolution:	320x240
Outline Dimension:	76.9063.93.26mm	Active Area:	70.08 X 52.56mm
Interface:	24-bit RGB	Viewing Angle:	80/80/80/80
Brightness:	350cd/m2	Display Mode:	TFT,Normally Black
Operating Temperatures:	-20 To 70 Degree	Storage Temperatures:	-30 To 80 Degree
Highlight:	320x240 IPS TFT LCD Display , IPS TFT LCD Screen

3.5-inch 320x240 IPS TFT LCD Display Module 3.5-inch TFT LCD Screen

Display General Description

General Data

Model Name	3.5 inch IPS TFT Display
Resolution	320x240
Model Size (WHT)	76.9063.93.26mm
Display Area (W*H)	70.08 x 52.56mm
Interface	RGB 24 bit
Display Mode	Normally Black,Transmissive
Viewing	IPS
Brightness	350 cd/m2
Pin number	40 pin
Driver IC	ST7272A
Operating temperatures	-20 to 70 ℃
Storage temperatures	-30 to 80 ℃

Drawing
3.5 inch 320x240 IPS TFT LCD Display Module 3.5-inch TFT LCD Screen 0

Product Details

3.5 inch 320x240 IPS TFT LCD Display Module 3.5-inch TFT LCD Screen 1

TFT Applications

This 3.5 inch IPS TFT Display can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports rgb interface.

3.5 inch 320x240 IPS TFT LCD Display Module 3.5-inch TFT LCD Screen 3
