Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface

Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface
Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface

Large Image :  Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface

Product Details:
Place of Origin: Guangdong,China
Brand Name: AISON
Certification: ISO9001 / ISO14000/ROHS
Model Number: Z043WQ34J
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton/Blister
Delivery Time: 7 working days
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Supply Ability: 200k/month
Contact Now

Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface

Description
LCM Name: 4.3 Inch IPS TFT LCD Display Resolution: 480x272
Module Dimension: 105.45*67.15*3mm Active Area: 95.04 X 53.856 Mm
Interface: 24 Bit RGB Luminance: 1000 Cd/m2
Operating Temperatures: -30 To 80 Degree Storage Temperatures: -30 To 85 Degree
Driver IC: ILI6485

Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface



General Description



This 4.3” IPS TFT LCD display has a resolution of 480x272 pixels and have a high brightness LED backlight with 1000 nits. The display offers stunning sharpness, superior color reproduction, better image consistency, and high contrast with full viewing angles due to the IPS technology built into this Liquid Crystal Display. The super bright backlight allows this TFT to be sunlight readable in bright conditions including direct sun. This 4.3 inch IPS display make it an excellent choice for projects that desire high-end visual output.


This 4.3” IPS TFT has a viewing angle wider than TN TFT, its viewing angles are Left:85 / Right:85 / Up:85 / Down:805degrees (typical value). The supply voltage for LCM (VCC) is from 3.0V to 3.6V. The module has a glare-surface glass, 16:9 aspect ratio, 1000:1 contrast ratio (typical value). It can operate at wide temperatures from -20℃ to +70℃ and its storage temperatures are from -30℃ to +80℃.



General Data

Model Name 4.3 inch IPS TFT LCD
Resolution 480x272
Model Size (W*H*T) 105.45*67.2*3 mm
Display Area (W*H) 95.04 x 53.856 mm
Interface 24 Bit RGB
Display Mode Normally Black,Transmissive
Viewing IPS
Brightness 1000 cd/m2
Pin number 40 pin
Driver IC ILI6485
Operating temperatures -20 to 70℃
Storage temperatures -30 to 80 ℃





Drawing
Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface 0





Product Details



Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface 1Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface 2





TFT Applications



This 4.3 inch IPS TFT LCD Displays are suitable for various applications, including embedded systems, industrial devices, security systems, medical equipment, consumer electronics, and handheld devices. Its adaptability and compatibility make it an excellent choice for a wide range of projects.

Sunlight Readable 4.3 Inch 480x272 IPS TFT Module Display1000Cd/M2 RGB Interface 3
