7 Inch 1024x600 Industrial TFT Display Active Matrix TFT Color LCD Display

Large Image : 7 Inch 1024x600 Industrial TFT Display Active Matrix TFT Color LCD Display

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	AISON
Certification:	ISO9001 / ISO14000/ROHS
Model Number:	Z070WS03

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable based on quantity
Packaging Details:	Carton/Blister Package
Delivery Time:	7 working days
Payment Terms:	T/T, Western Union, MoneyGram,Paypal
Supply Ability:	200k/month

Contact Now

7 Inch 1024x600 Industrial TFT Display Active Matrix TFT Color LCD Display

Description

Name:	7 Inch Industrial TFT Display	Resolution:	1024X600
Outline Dimension:	164.91003.5mm	Active Area:	154.21 X 85.92mm
Interface:	RGB	Brightness:	400 Cd/m2
LCD Type:	TFT, Normally White, Transmissive	Contrast Ratio:	800:1
Operating Temperatures:	-20℃ To +70℃	Storage Temperatures:	-30℃ To +80℃
Highlight:	1024x600 Industrial TFT Display , Industrial TFT Display 7 Inch , Active Matrix TFT Color LCD

1024x600 Industrial TFT Display 7 Inch Active Matrix TFT Color LCD Display

General Description

Z070WS03 is a 7-inch TN transmissive type color active matrix TFT LCD with a resolution of 1024x600 pixels with RGB 50 pin interfacce.
The display features an aspect ratio of 16:9. The power voltage (DVDD) ranges from 3.0V to 3.6V, with a typical value of 3.3V. It includes an anti-glare surface panel, with an viewing direction 75/70/75/75. The brightness ranges from 400 nits to 450 nits.

This 7 inch TFT Displays Operating temperatures range from -20°C to +70°C, with storage temperatures from -30°C to +80°C. This TFT display model is suitable for various industrial control product applications.

General Data

Model Name	7 inch RGB TFT Display
Resolution	1024x600 mm
Model Size (WHT)	164.91003.5 mm
Display Area (W*H)	154.21 x 85.92
Interface	RGB
Display Mode	Normally White,Transmissive
Viewing	12 o'clock
Brightness	400 cd/m2
Pin number	50 pin
Contrast Ratio	800:1
Operating temperatures	-20 to 70 degree
Storage temperatures	-30 to 80 degree

Drawing
7 Inch 1024x600 Industrial TFT Display Active Matrix TFT Color LCD Display 0

Product Details

TFT Applications:

This 7 inch TFT LCD module is well-suited for applications in industrial control equipment, testing devices, medical equipment, and smart home devices, among others. Due to its versatility, this TFT LCD module is suitable for a variety of application scenarios.

7 Inch 1024x600 Industrial TFT Display Active Matrix TFT Color LCD Display 5
