4 Inch Square LCD IPS 720x720 TFT Display 4 Inch Square LCD Touch Screen For 86 Box Smart Home

Large Image : 4 Inch Square LCD IPS 720x720 TFT Display 4 Inch Square LCD Touch Screen For 86 Box Smart Home

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	AISON
Certification:	ISO9001 / ISO14000/ROHS
Model Number:	Z040HD-30MRB-A1

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Blister Package/Carton
Delivery Time:	7 working days
Payment Terms:	T/T
Supply Ability:	100k/month

Contact Now

4 Inch Square LCD IPS 720x720 TFT Display 4 Inch Square LCD Touch Screen For 86 Box Smart Home

Description

Name:	4 Inch Square Touch TFT Display	Resolution:	720x720
Outline Dimension:	84.00(H) 84.00(V)3.2(T)	Active Area:	71.93 (H)*71.93(V)
Interface:	MIPI 4 Lane	Viewing Angle:	85/85/85/85
Brightness:	300 Cd/m2	Display Mode:	Normally Black
Driver IC:	FL7707	Operating Temperatures:	-20℃~ +70℃
Storage Temperatures:	-30℃~ +80℃
Highlight:	4 inch square LCD touch screen , IPS TFT display 720x720 , smart home square LCD display

4 Inch Square LCD IPS 720x720 TFT Display 4 Inch Square LCD Touch Screen For 86 Box Smart Home

Display General Description

This 3.95 inch (4 inch)square lcd module is equipped with the FL7707 driver IC and supports MIPI interface.

It has a 720x720 RGB pixel resolution on a black background, delivering an exceptional visual experience.
The module's brightness of 300cd/m2 with captouch screen ensures clear visibility in various lighting conditions, providing optimal viewing comfort.

It can be operating at temperatures from -20℃ to +70℃ and storage temperatures from -30℃ to +80℃.

General Data

Model Name	4 Inch Square Touch TFT LCD Display
Resolution	720x720
Model Size (WHT)	84.00(H) 84.00(V)3.2(T)
Display Area (W*H)	71.93 (H)*71.93(V)
Interface	MIPI 4 Lane
Display Mode	Normally Black,Transmissive
Viewing	All/IPS
Brightness	300 cd/m2
Pin number	30
Drive IC	FL7707
Touch	Capacitive Touch Panel Optional
Operating temperatures	-20 to 70 degree
Storage temperatures	-30 to 80 degree

Drawing

4 Inch Square LCD IPS 720x720 TFT Display 4 Inch Square LCD Touch Screen For 86 Box Smart Home 0

Product Details

4 Inch Square LCD IPS 720x720 TFT Display 4 Inch Square LCD Touch Screen For 86 Box Smart Home 2

TFT Applications

This square TFT LCD panel is particularly well-suited for industrial control systems, portable measurement instruments, outdoor display systems, and home automation panels.The 3.95 inch square form factor makes it a versatile display solution for a variety of compact and portable devices.
