7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3

7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3
7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3

Large Image :  7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3

Product Details:
Place of Origin: Guangdong,China
Brand Name: AISON
Certification: ISO9001 / ISO14000/ROHS
Model Number: DSI700-V1.0I
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable based on quantity
Packaging Details: Blister Package/Carton
Delivery Time: 7 working days for samples;3-4 weeks for mass production
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Supply Ability: 200k/month
Contact Now

7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3

Description
Name: 7 Inch DSI Touch Display Resolution: 1024x600
Outline Dimension: 164.9*100*10.8mm Active Area: 154.08x85.92mm
Interface: MIPI DSI Viewing Angle: 85/85/85/85
Brightness: 450cd/m2 Display Mode: Normally Black
Viewing Direction: ALL/IPS Operating Temperatures: -20 To 70 Degree
Storage Temperatures: -30 To 80 Degree
Highlight:

7 inch MIPI-DSI IPS LCD display

,

Raspberry Pi touch screen

,

HDMI TFT display with capacitive touch

7 Inch 800*480 MIPI-DSI IPS LCD Display Capacitive Touch Screen Module for Raspberry Pi



General Description



DSI700-V1.0I is a 7inch LCD display driver board; Supports DSI input; Support capacitive touch panel.





General Spec



Model Name 7 inch DSI LCD Touch Display
Resolution 800x480/1024x600
Model Size (W*H*T)mm 164.9*100*10.8mm
Display Area (W*H)mm 154.08x85.92
Interface MIPI DSI
Display Mode Normally Black,Transmissive
Viewing All/IPS
Brightness 450 cd/m2
Pin 50
Touch Captouch
Application For Raspberry Pi
Operating temperatures -20 to 70 degree
Storage temperatures -30 to 80 degree







Drawing



7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 0





Product Details

7 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 17 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 27 inch MIPI-DSI IPS LCD Display Capacitive Touch Screen for Raspberry Pi 5 4 3 3







TFT Applications



This 7 inch MIPI DSI Touch Display 800x480 IPS TFT LCD Toudh Display application:



1,.Used as a monitor, supports Raspbian, Ubuntu, Kodi, win10 IOT, single-touch, driver-free

2.Used as a computer monitor, supports 5-point touch for win7, win8, win10 and win11 systems (single-touch for XP and older systems), driver-free
