15.6 Inch 1920×1080 Full IPS TFT LCD Display Module LVDS Touch Screen Panel

Large Image : 15.6 Inch 1920×1080 Full IPS TFT LCD Display Module LVDS Touch Screen Panel

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	AISON
Certification:	ISO9001 / ISO14000/ROHS
Model Number:	Z156FH03-CT2

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Carton/Blister
Delivery Time:	7 working days
Payment Terms:	T/T, Western Union, MoneyGram,Paypal
Supply Ability:	200k/month

Contact Now

15.6 Inch 1920×1080 Full IPS TFT LCD Display Module LVDS Touch Screen Panel

Description

Product Name:	15.6 Inch 1920x1080 LVDS TFT Display	Resolution:	1920x1080
Module Size:	372.16221.598.2mm	Active Area:	344.16 (H) ×193.59 (V) Mm
LCM Type:	LVDS	Brightness:	500/1000 Cd/m2
Operating Temperatures:	-20 To 70 Degree	Storage Temperatures:	-30 To 80 Degree
Display Type:	Normally Black	Touch:	PCAP Touch
Touch Interface:	USB &I2C
Highlight:	Touch Screen TFT LCD Display Module , IPS TFT LCD Display Module , 15.6 Inch TFT LCD Display Module

15.6 inch 1920×1080 Full IPS TFT LCD Display Module LVDS Touch Screen Panel

General Description

This 15.6 inch tft lcd display is characterised by deeply saturated colours, strong contrasts with a ratio of 800:1 and a brightness of 1000 cd/m². The white LED backlight guarantees a service life of 50,000 hours at half brightness. An integrated LED driver circuit enables flicker-free dimming from 0 to 100 % via a PWM input signal.

With an operating temperature range of -20°C to +70°C, the display is ideal for demanding environments such as outdoor applications, automotive systems, marine and medical devices. It supports LVDS interface and USB and I2C PCAP touch screen.

General Data

Model Name	15.6 inch PCAP LVDS TFT Display
Resolution	1920x1080
Model Size (WHT)	372.16221.598.2mm
Display Area (W*H)	344.16 (H) ×193.59 (V) mm
Interface	LVDS
Display Mode	Normally Black,Transmissive
Viewing Angles	85/85/85/85
Brightness	1000 cd/m2
Pin number	30 pin
Touch	with Capacitive Touch Panel
Operating temperatures	-20 to 70 ℃
Storage temperatures	-30 to 80 ℃

Drawing

15.6 Inch 1920×1080 Full IPS TFT LCD Display Module LVDS Touch Screen Panel 0

Product Details

15.6 Inch 1920×1080 Full IPS TFT LCD Display Module LVDS Touch Screen Panel 2

TFT Applications

From industrial machinery and equipment to HMI (Human-Machine Interface) systems, POS (Point of Sale) terminals, and outdoor vending systems, this high resolution TFT LCD display module offers excellent performance and reliability.

15.6 Inch 1920×1080 Full IPS TFT LCD Display Module LVDS Touch Screen Panel 5
