5 Inch 800x480 IPS LVDS TFT LCD Module with USB Interface Capacitive Touch Screen

Large Image : 5 Inch 800x480 IPS LVDS TFT LCD Module with USB Interface Capacitive Touch Screen

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	AISON
Certification:	ISO9001 / ISO14000/ROHS
Model Number:	Z050WV31-CT

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10~25usd/p
Packaging Details:	Blister Package/Carton
Delivery Time:	7 working days
Payment Terms:	T/T
Supply Ability:	200k/month

Contact Now

5 Inch 800x480 IPS LVDS TFT LCD Module with USB Interface Capacitive Touch Screen

Description

Name:	5 Inch IPS TFT Display With USB Touch Screen	Resolution:	800x480
Module Size:	133.993.45.5mm	Active Area:	108 X 64.80 Mm
Interface Type:	LVDS 6/8 Bit	Luminance:	350 Cd/m2
Display Mode:	Normally Black	Viewing Angles:	85/85/85/85
Operating Temperatures:	-30 To 80 Degree	Storage Temperatures:	-35 To 85 Degree
Highlight:	USB Interface Capacitive Touch Screen , LVDS TFT LCD Module , 5 Inch Capacitive Touch Screen

5 Inch 800x480 IPS LVDSTFT LCD Module with USB Interface CapacitiveTouch Screen

Display General Description

Z050WV31-CT is a 5-inch TFT LCD module designed for exceptional performance and versatility. This module features a resolution of 800 × 480 pixels with a 16:9 aspect ratio, delivering a wide and immersive viewing experience. Equipped with a projected capacitive touch screen and IPS display technology, it offers a viewing angle of 85 degrees in all directions, ensuring clarity from every angle.This 5 inch lcd display is with LVDS interface with USB Interface CapacitiveTouch Screen.

Designed for robust operation, this module is capable of functioning within a wide temperature range of -30℃ to +80℃, with storage temperatures as low as -35℃ and as high as +85℃, making it suitable for diverse environments. It features a contrast ratio of 800:1 (typical) and a brightness of 350 nits (typical), delivering crisp and vivid visuals under various lighting conditions.

General Data

Product Name	5 Inch Capacitive Touch IPS TFT LCD Module
Number of Pixel	800x480
Interface	LVDS
Luminance(cd/m2)	400 cd/m2
Active area	133.993.45.5
LCM (W x H x D)	108x64.8 mm
Viewing Direction(eye)	IPS/ALL
Operating temperatures	-30 to 80 degree
Storage temperatures	-35 to 85 degree

Drawing
5 Inch 800x480 IPS LVDS TFT LCD Module with USB Interface Capacitive Touch Screen 0

Product Details

5 Inch 800x480 IPS LVDS TFT LCD Module with USB Interface Capacitive Touch Screen 1

TFT Applications

The 5 inch display module is suitable for use in control panels for white goods, industrial control systems, audio equipment, and home security systems.

5 Inch 800x480 IPS LVDS TFT LCD Module with USB Interface Capacitive Touch Screen 2
