Product Details:
|
| Product Name: | 3.5 Inch 640x480 IPS TFT Display | Resolution: | 640x480 |
|---|---|---|---|
| Outline Dimension: | 76.90*63.9*3.26mm | Active Area: | 70.08 X 52.56mm |
| Interface: | RGB | Brightness: | 1000cd/m2 |
| IC Or Equivalent: | NV3052C | Working Temperatures: | -20 To 70 Degree |
| Storage Temperatures: | -30 To 80 Degree | ||
| Highlight: | 3.5 Inch IPS Display,IPS Display High Brightness,640x480 LCD Display 1000cd/m2 |
||
3.5 inch High Brightness IPS 640x480 TFT LCD Display with RGB Interface
General Data
| Model Name | 3.5 inch IPS TFT LCD |
| Resolution | 640x480 |
| Model Size (W*H*T) | 76.90*63.9*3.26mm |
| Display Area (W*H) | 70.08 x 52.56mm |
| Interface | RGB |
| Display Mode | Normally Black,Transmissive |
| Viewing | IPS |
| Brightness | 1000 cd/m2 |
| Pin number | 54 pin |
| Driver IC | NV3052C |
| Operating temperatures | -20 to 70 ℃ |
| Storage temperatures | -30 to 80 ℃ |
Drawing
Product Details
TFT Applications
This 3.5 inch 640x480 IPS LCD Module can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports RGB interface.
